Minimum Order Quantity: 1pc
Control System: |
PLC Control |
Product Size Range: |
Customizable |
Operation Mode: |
Automatic |
Power Supply: |
380V/50Hz |
Heating Temperature: |
Adjustable |
Production Capacity: |
100-500 Pieces Per Hour |
Application: |
For Manufacturing Electric Water Heaters |
Material: |
Stainless Steel |
After-Sales Service: |
Online Support |
Installation: |
Provided By Supplier |
Heating Method: |
Electric Heating |
Warranty: |
1 Year |
Cooling Method: |
Water Cooling |
Product Name: |
Electric Water Heater Production Line |
Color: |
Customized |
Automatic Grade: |
Automatic |
Voltage: |
Customized |
Applicable Industries: |
Building Material Shops |
Condition: |
New |
Control System: |
PLC Control |
Product Size Range: |
Customizable |
Operation Mode: |
Automatic |
Power Supply: |
380V/50Hz |
Heating Temperature: |
Adjustable |
Production Capacity: |
100-500 Pieces Per Hour |
Application: |
For Manufacturing Electric Water Heaters |
Material: |
Stainless Steel |
After-Sales Service: |
Online Support |
Installation: |
Provided By Supplier |
Heating Method: |
Electric Heating |
Warranty: |
1 Year |
Cooling Method: |
Water Cooling |
Product Name: |
Electric Water Heater Production Line |
Color: |
Customized |
Automatic Grade: |
Automatic |
Voltage: |
Customized |
Applicable Industries: |
Building Material Shops |
Condition: |
New |
The CNC shearing machine consists of a CNC control cabinet, an electric shearing machine, a leveling machine, a material support frame, and a laminating part. Its operation is simple with one-time setting for automatic shearing which saves time and effort. It finds extensive application in the processing and production of solar inner and outer bladders, brackets, barrel supports etc., mainly used for cutting various types of plates without any restriction on their length or width.
Mechanical shears
The CNC shearing machine consists of a CNC control cabinet, an electric shearing machine, a leveling machine, a material support frame, and a laminating part. Its operation is simple with one-time setting for automatic shearing which saves time and effort. It finds extensive application in the processing and production of solar inner and outer bladders, brackets, barrel supports etc., mainly used for cutting various types of plates without any restriction on their length or width..
Product parameters
|
Device name |
Mechanical shears |
|
|
Device model |
LPS02 |
|
|
Shear thickness (mm) |
0.1-12 |
|
|
Maximum shear force (KN) |
580 |
|
|
Shearing Angle (°) |
0.5-2.5 |
|
|
The total number of trips (/min) |
9 |
|
|
Distance between columns |
2800 |
|
|
Maximum distance of back gauge (mm) |
1000 |
|
|
Blade length (mm) |
2500 |
|
|
The height of the table from the ground (mm) |
850 |
|
|
Throat depth (mm) |
100 |
|
|
Main motor power (KW) |
15 |
|
|
Speed (r/min) |
1470 |
|
|
Internal gear rotary pump flow (MI/r) |
38 |
|
|
System maximum working pressure (Mpa) |
Twenty two |
|
|
Dimensions |
Length (mm) |
3260 |
|
Width (mm) |
2150 |
|
